Tempo PE2003-G Includes

• (1) 12V Battery for Transmitter
• (1) 9V Battery for Receiver
• Molded Carrying Case
• Rechargeable Transmitter
• Receiver
• AF2 A-frame
• Ground stake
• 120V charger
• 12V DC (cigarette lighter) adapter.

Tempo PE2003-G Features

• Identifies the exact location of even the smallest breaks in insulation by “pulsing” a high-voltage signal that radiates into the earth at the location of the faults. With the A-frame mounted receiver, a visual analog meter points the way to the source of the voltage.
• Multiple faults on a single wire can be identified indicating the need to replace instead of repair.
• Extra-long test leads feature heavy-duty alligator clips for use on multiple cable types.
• Battery operated

Tempo PE2003-G Specifications

Power Requirements: Transmitter – (1) 12V rechargeable battery; Receiver – (1) 9V battery Battery Life: Transmitter – 23 hours per charge; Receiver – 200 hours Transmitter Power: 2400 VDC peak Voltage Protection: 240VAC/400VDC Construction – Transmitter: aluminum housing in polyethylene case Construction – Receiver: powder coated aluminum Dimensions – Transmitter: 17″ x 8.5″ x 6.5″ (421 mm x 215 mm x 160 mm) in case Dimensions – Receiver: 33.5″ x 21.75″ x 3.25″ (840 mm x 550 mm x 8 mm) on A-frame
